TPT-1400 1 Ohm
TPT-1400 1 Ohm is backordered and will ship as soon as it is back in stock.
Warranty Information
Warranty Information
Timpano Audio warrants all new products from any manufacturing defects in materials or workmanship under normal usage for a period not to exceed (1) year from the original purchase date.
If you need assistance for a warranty claim, please choose visit this page - Warranty Center
Delivery and Shipping
Delivery and Shipping
FREE SHIPPING! - 48-States on Orders Over $18 - Order before 1PM EST and Your Order will Ship on the Same Day
Description
Description
Timpano amplifiers raises power amplification to a new standard of quality and usability. The new line delivers the most innovative and powerful Brazilian technology in compact full range amplifiers on the market. Loaded with features, it provides an unsurpassed efficiency rate of 85-95% in a compact Class D full range amplifier.
Number of Channels: 1
RMS Power at 1 Ohm 12.6V: 1200W RMS
RMS Power at 2 Ohm 12.6V: 600W RMS
RMS Power at 4 Ohm 12.6V: ——
RMS Power at 1 Ohm 14.4V: 1400W RMS
RMS Power at 2 Ohm 14.4V: 700W RMS
RMS Power at 4 Ohm 14.4V: ——
Supply Voltage: 11 ~ 16V
Frequency Response: 20Hz ~ 18KHz
Crossover Low Pass: 50Hz ~ 2KHz
Crossover High Pass: 50Hz ~ 2KHz
Signal to Noise: > 90 dB
Harmonic Distortion: < 0.9 % THD
Input Sensitivity: 2.8V
Input Impedance: 10K OHM
Impedance Output: 1 OHM
Consumption with Signal Musical: 3A ~ 80A
Consumption with Signal Bass: 3A ~ 150A
Dimensions (L x W x H): 5.57” x 7.28” x 2”
Weight: 2.73 Lbs
